GasAlertClipExtreme 24 Carbon Monoxide (CO).
GasAlertClipExtreme 24 Carbon Monoxide (CO).
Discontinued!
This product has been discontinued and is no longer available.
This is the direct replacement:
| Gas monitored: | H2S | CO | SO2 | O2 |
| Sensor range: | 0 - 100 ppm | 0 - 300 ppm | 0 - 100 ppm | 0 - 30.0% by vol. |
| Low alarm level: | 10 ppm | 35 ppm | 5 ppm | 19.5 % |
| High alarm level: | 15 ppm | 200 ppm | 10 ppm | 23.5 % |
| Operating Temperature: | -40 to +122 °F -40 to +50 °C |
-22 to+122°F -30 to +50°C |
-22 to +122 °F -30 to +50 °C |
-4 to +122 °F -20 to +50 °C |
| Calibration: | Not required | Self-calibrating | ||
| GENERAL SPECIFICATIONS | Rugged composite material with integral concussion-proof boot |
| Humidity | 5% to 95% RH (non-condensing) |
| EMI/RFI | Complies with EMC Directive 89/336/EEC |
| Ingress protection | IP 66/67 |
| Battery | Lithium, non-replaceable |
| Size | 28 x 50 x 81 mm / 1.1 x 2.0 x 3.2 inches |
| Weight | 76 g / 2.7 oz. |
| WARRANTY | 2 years from activation plus 1 year shelf-life |
| Operational life | Two years3 |
| Continuously on | Yes |
| One-button control | Activation, self-test and alarm event data transmission |
| Full function self-test | Verifies integrity of sensor, circuitry and battery; audible/visual alarms |
| Sensor | Electrochemical cell (temperature compensated) |
| INDICATORS AND ALARMS | |
| Visual gas alarm | Flashing, wide-angled alarm lens with dual red LEDs plus ALARM LCD readout |
| Audible gas alarm | Pulsing siren 85 dB at 0.3 m / 1 ft. |
| Vibrator alarm | Internal |
| Failure alarm | Yes (audible/visual) |
| Self-test pass | Yes (audible/visual) |
| Other | Low battery and end of life (audible/visual) |
| CONTINUOUS LCD DISPLAY | Alphanumeric status panel LCD advises |
| Life remaining | Continuously displayed in months, then days, then hours |
| Two alarm levels | LOW alarm / HIGH alarm |
| Peak alarm exposure | Records and displays peak alarm exposure, and time elapsed (up to 24 hrs.) |
| Alarm setpoints | High and low (displayed on demand in ppm or %) |
| Self-test status | Advises to "TEST" and that self-test was passed "." |
| TESTS | |
| Full function self-test | On-demand, as often as once every 20 hours and on activation |
| Battery | Every two hours (auto) |
| EVENT LOGGING | Records and transmits up to 10 gas alarm events |
| Event information | Gas type, peak exposure level (ppm or %); alarm duration in minutes and seconds; time elapsed since the alarm occurred in days, hours and minutes |
| Transmission method | Via infrared port to thermal printer or USB |
There are many gas detection products on the market that might appear to be the same, but a closer inspection of specification, functionality and features reveals major differences in what products can do and the potential value they can offer. Similarly, individual applications are also unique in their respective designs, needs and processes undertaken.
Before beginning to consider gas detection equipment, a risk assessment needs to be conducted. Any company employing staff has the obligation to conduct risk assessments to identify potential hazards and these can include potential gas, vapor or Oxygen deficiency risks. If gas hazards are identified, gas detection is applicable as a risk reduction method.
Depending on the processes being undertaken and the gases being detected, remote or off-site alarm notification plus event data logging/reporting may also be required for Health and Safety management records. Another factor impacting on the need for enhanced reporting functions might be regulatory compliance or a condition of insurance.
Having identified the primary objective, the suitable equipment is selected by asking a number of key questions. These fall into three broad categories:
The gases to be detected should be identified by the risk assessment, however experienced gas detection equipment manufacturers and their approved distributors are often able to help in this process, based on their experience of similar applications. However, it is important to remember that it is the end-user’s responsibility to identify all potential hazards. It is also essential to identify the potential source of a gas release as this helps determine the number and location of detectors required for a fixed gas detection system.
The performance, accuracy and reliability of any gas detection equipment will be affected by the environmental conditions it is subjected to. Temperature, humidity and pressure levels at the location all have a direct bearing on the type of equipment that should be selected. Additional factors such as potential variations resulting from a production process itself, diurnal/nocturnal fluctuations and seasonal changes may also affect the type of device which is suitable.
The next area of consideration relates to additional product functionality. Aspects like wiring configuration are important, especially when retro-fitting into an existing application. If the apparatus is being integrated into a separate safety system, certain communication protocols may also be required such as HART®, Lonworks or Modbus®. Consideration will also need to be given regarding the requirement for local displays on transmitter units and local configuration of the unit and gas displays may also be a useful addition.
Routine maintenance is another important consideration. Some gases and vapors can be detected with a number of different sensing technologies, e.g. Hydrocarbon gases with catalytic beads or Non-dispersive Infrared NDIR. Catalytic beads do not provide fail-to-safety operation and therefore can require a high frequency of routine maintenance, however NDIR based solutions tend to have a higher initial purchase price, but may require less routine maintenance. In-house resource to undertake such routine maintenance needs to be identified and in the absence of such a resource, budgeting for third party maintenance is an important factor in selecting the right equipment.
If you have questions about any of our gas detection products or services, please don’t hesitate to contact us. Whether you need a hand finding a new product or need help with your current system, just ask our team of Factory Trained Experts.
Small, compact, easy to use and virtually maintenance free. Always active means you will never forget to turn on your monitor.
No real-time display of current gas levels. Cannot be turned off, once it is turned on the 24 or 36 month countdown begins and there is no delaying or stopping that.
An excellent monitor to use if you only need to know when the target gas is present. Not the monitor to use if you need an exact reading in real-time. It has a good history of being reliable and virtually problem free.
A popular unit, this low-maintenance gas detector is a good choice for anyone wanting continuous, reliable protection in a low cost single gas detector with minimal maintenance requirements. It is a good fit in virtually any application as a quick and easy safety device.
There is no need for calibration, sensor replacement, battery replacement or battery charging on this model. Regular maintenance Bump Tests can be performed on the unit depending on personal preference or when site safety regulations require it.
Available sensors include H2S, CO, SO2 and Oxygen, but as a single gas detector you can choose only one of those sensors available, not multiple sensors. With H2S and CO, you can choose either a 2 or a 3 year version. A daily self-test, which is activated by the press of a button, performs a full function self-test of the sensor, battery, circuit integrity as well as the visual and audible alarms, providing user confidence. The built-in concussion proof boot provides excellent protection against accidental bumps, scratches and damage; and it is water-proof, with an IP rating of 67 it can be submerged in water up to 1 m deep for 30 minutes.
The GA24XT doesn't give you an actual real-time readout of current gas levels, those are only seen when the detected levels reach the point that the alarms are triggered; during non-alarm periods only the life remaining of the unit is displayed. It also can't be turned off once it has been activated. This is generally a concern for contract workers, who like the GA24XT because of its low price and ease of use, but some contracts only last a couple months with more time between contracts. Not being able to turn off or "hibernate" the unit limits your lifespan. It is also compatible with the BW MicroDock II calibration and bump test station for those who wish to use a more hands-free, automated, bump test procedure.
Click on a category to view a selection of compatible accessories with the BW GA24XT-M GasAlertClipExtreme 24.
